消费电子产品应用晶振DSC1018DI1-028.6363T
Microchip晶振DSC1018是一个1.8V固定频率MEMS基于纯硅™振荡器。它可以被工厂编程到从1到150MHz的任何频率。DSC1018包含了一个全硅谐振器，它非常坚固，几乎不受应力相关裂缝的影响，这是石英晶体振荡器常见的。在不牺牲当今系统所需的性能和稳定性的情况下，无晶体设计允许更高水平的可靠性，DSC1018非常适合坚固的工业和便携式应用，其中应力、冲击和振动可能会损害基于石英晶体的系统。可在工业标准软件包，贴片晶振DSC1018可以“插入”到相同的PCB足迹作为标准晶体振荡器。应用程序：移动应用，消费电子产品，便携式电子设备，VTR摄像机的CCD时钟，低配置文件应用，工业用等。消费电子产品应用晶振DSC1018DI1-028.6363T
| 进口有源晶振 | 品牌 | 型号 | 频率 | 电压 | Type 类型 |
| DSC1018BC1-054.0000 | Microchip晶振 | DSC1018 | 54MHz | 1.8V | MEMS (Silicon) |
| DSC1018BC1-100.0000 | Microchip晶振 | DSC1018 | 100MHz | 1.8V | MEMS (Silicon) |
| DSC1018CE1-026.0000T | Microchip晶振 | DSC1018 | 26MHz | 1.8V | MEMS (Silicon) |
| DSC1018CI1-038.4000T | Microchip晶振 | DSC1018 | 38.4MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-012.0000T | Microchip晶振 | DSC1018 | 12MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-025.0000T | Microchip晶振 | DSC1018 | 25MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-028.6360T | Microchip晶振 | DSC1018 | 28.636MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-019.2000T | Microchip晶振 | DSC1018 | 19.2MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-019.2000 | Microchip晶振 | DSC1018 | 19.2MHz | 1.8V | MEMS (Silicon) |
| DSC1018DC1-080.0000T | Microchip晶振 | DSC1018 | 80MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-048.0000T | Microchip晶振 | DSC1018 | 48MHz | 1.8V | MEMS (Silicon) |
| DSC1018CI2-022.5792T | Microchip晶振 | DSC1018 | 22.5792MHz | 1.8V | MEMS (Silicon) |
| DSC1018CI2-022.5792 | Microchip晶振 | DSC1018 | 22.5792MHz | 1.8V | MEMS (Silicon) |
| DSC1018BC1-054.0000T | Microchip晶振 | DSC1018 | 54MHz | 1.8V | MEMS (Silicon) |
| DSC1018DE1-125.0000T | Microchip晶振 | DSC1018 | 125MHz | 1.8V | MEMS (Silicon) |
| DSC1018BC1-080.0000T | Microchip晶振 | DSC1018 | 80MHz | 1.8V | MEMS (Silicon) |
| DSC1018BI1-125.0000T | Microchip晶振 | DSC1018 | 125MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-015.0000 | Microchip晶振 | DSC1018 | 15MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-024.0000 | Microchip晶振 | DSC1018 | 24MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-024.0000T | Microchip晶振 | DSC1018 | 24MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-026.0000T | Microchip晶振 | DSC1018 | 26MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-027.0000T | Microchip晶振 | DSC1018 | 27MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-026.0000 | Microchip晶振 | DSC1018 | 26MHz | 1.8V | MEMS (Silicon) |
| DSC1018DE1-024.0000 | Microchip晶振 | DSC1018 | 24MHz | 1.8V | MEMS (Silicon) |
| DSC1018DE1-024.0000T | 进口晶振 | DSC1018 | 24MHz | 1.8V | MEMS (Silicon) |
| DSC1018DC2-024.0000 | Microchip晶振 | DSC1018 | 24MHz | 1.8V | MEMS (Silicon) |
| DSC1018DC2-024.0000T | Microchip晶振 | DSC1018 | 24MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-015.0000T | Microchip晶振 | DSC1018 | 15MHz | 1.8V | MEMS (Silicon) |
| DSC1018BE1-024.0000T | Microchip晶振 | DSC1018 | 24MHz | 1.8V | MEMS (Silicon) |
| DSC1018BE1-028.6363T | Microchip晶振 | DSC1018 | 28.6363MHz | 1.8V | MEMS (Silicon) |
| DSC1018BE1-050.0000T | Microchip晶振 | DSC1018 | 50MHz | 1.8V | MEMS (Silicon) |
| DSC1018CE2-040.0000T | Microchip晶振 | DSC1018 | 40MHz | 1.8V | MEMS (Silicon) |
| DSC1018CI1-026.0000T | Microchip晶振 | DSC1018 | 26MHz | 1.8V | MEMS (Silicon) |
| DSC1018CI1-100.0000T | Microchip晶振 | DSC1018 | 100MHz | 1.8V | MEMS (Silicon) |
| DSC1018DC1-022.0000B | Microchip晶振 | DSC1018 | 22MHz | 1.8V | MEMS (Silicon) |
| DSC1018DC1-022.0000D | Microchip晶振 | DSC1018 | 22MHz | 1.8V | MEMS (Silicon) |
| DSC1018DC1-022.0000T | Microchip晶振 | DSC1018 | 22MHz | 1.8V | MEMS (Silicon) |
| DSC1018DC2-026.0000T | Microchip晶振 | DSC1018 | 26MHz | 1.8V | MEMS (Silicon) |
| DSC1018DE1-004.7500T | Microchip晶振 | DSC1018 | 4.75MHz | 1.8V | MEMS (Silicon) |
| DSC1018DE2-040.0000T | Microchip晶振 | DSC1018 | 40MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-024.0000T | Microchip晶振 | DSC1018 | 24MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-028.6363T | Microchip晶振 | DSC1018 | 28.6363MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-050.0000T | Microchip晶振 | DSC1018 | 50MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-006.0000T | Microchip晶振 | DSC1018 | 6MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-025.0000T | Microchip晶振 | DSC1018 | 25MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-070.0000T | Microchip晶振 | DSC1018 | 70MHz | 1.8V | MEMS (Silicon) |
| DSC1018BE1-050.0000 | Microchip晶振 | DSC1018 | 50MHz | 1.8V | MEMS (Silicon) |
| DSC1018DE2-040.0000 | Microchip晶振 | DSC1018 | 40MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-012.0000 | Microchip晶振 | DSC1018 | 12MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-025.0000 | Microchip晶振 | DSC1018 | 25MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-006.0000 | Microchip晶振 | DSC1018 | 6MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI2-025.0000 | Microchip晶振 | DSC1018 | 25MHz | 1.8V | MEMS (Silicon) |
| DSC1018DE1-027.0000T | Microchip晶振 | DSC1018 | 27MHz | 1.8V | MEMS (Silicon) |
| DSC1018DC1-080.0000 | Microchip晶振 | DSC1018 | 80MHz | 1.8V | MEMS (Silicon) |
| DSC1018DE1-125.0000 | Microchip晶振 | DSC1018 | 125MHz | 1.8V | MEMS (Silicon) |
| DSC1018DI1-048.0000 | Microchip晶振 | DSC1018 | 48MHz | 1.8V | MEMS (Silicon) |
DSC1018晶振特点：
频率范围：1至150MHz
特殊温度稳定性：±25PPM，±50PPM
工作电压：1.65至1.95V贴片石英晶振
工作温度范围：工业-40ºC至+85ºC Ext。商业-20ºC~+70ºC ，商业0ºC~+70ºC
低操作和备用当前：3 mA操作（40MHz），1uA备用
超微型足迹：2.5x2.0x0.85毫米，3.2x2.5x0.85毫米，5.0x3.2x0.85毫米，7.0x5.0x0.85毫米
优秀的冲击和振动
无铅，RoHS &达到SVHC兼容
引脚“插入”替换的引脚 工业标准振荡器
半导体级可靠性明显高于石英
短批量生产交付周期
更长的电池寿命/更低的功耗
紧凑型塑料封装
具有成本效益
